Allied 8-Channel 16MP NVR with 8-Port PoE
$840.11
A premium eight-camera NVR with 16MP recording, eight PoE ports, 4K HDMI, RAID 1, AcuSearch, and up to 48TB across two drive bays.
- Direct PoE Connections for Eight Cameras
- Supports Premium Cameras up to 16MP
- Two Bays Expand Local Storage up to 48TB
- AcuSearch and AcuTrack Speed Up Review
- Advanced Face, Plate and Perimeter Analytics
Connection & Power
Storage & Access
Resolution
Higher resolution records more pixels in each frame, which gives you more detail to work with when reviewing faces, vehicles, packages, and activity.
Resolution labels describe output dimensions. Aspect ratio, lens quality, sensor quality, lighting, compression, and recorder settings also affect usable image detail.
Frame Rate
Frame rate measures how many images a camera records each second. Higher FPS makes fast movement appear smoother and easier to follow.
The highlighted lane shows this product's maximum listed frame rate. Actual FPS can vary by resolution, recording mode, recorder, and system settings.
Description
The Allied 8-Channel 16MP NVR is built for an eight-camera system where image quality and retention carry more weight than channel count. Eight built-in PoE ports simplify camera connections, and the recorder accepts streams up to 16MP for detailed views of gates, drive lanes, cash-handling areas, and other evidence-critical locations.
Two SATA bays support up to 24TB each, providing 48TB total capacity, with RAID 1 available when mirrored storage is preferred. Ultra 265 compression and ANR help protect the recording plan, while 4K HDMI provides clear local review. Allied can pair this NVR with the right security and surveillance cameras so high resolution is used where it produces genuinely better evidence.
AcuSearch and AcuTrack make it easier to locate and follow a person or vehicle across compatible cameras. Face, vehicle, human-body, people-counting, and heat-map searches add more ways to investigate activity. This model suits a refined eight-camera design that needs deep storage and advanced search rather than unused inputs.
Key Features
- 8 IP channels with 8 built-in PoE ports
- Up to 16MP recording resolution
- 4K HDMI output
- Two drive bays, up to 24TB each and 48TB total
- RAID 1 and ANR recording protection
- Ultra 265, H.265, and H.264 compression
- AcuSearch, AcuTrack, and advanced video analytics
Full Specifications
- Megapixels:
- 16
- Resolution:
- 4K
- FPS:
- 30
- Smart Features:
- AcuSearch, AcuTrack, Face Capture, Facial Recognition, Intelligent people flow counting, License Plate Reader, Smart Intrusion Prevention, UMD (human,vehicle,pet) Detection, Video Analytics
- Built-in PoE Ports:
- 8
- Channels:
- 8
- Decoding Format:
- H.264, H.265, Ultra 265
- DVR/NVR Storage Capacity:
- 48TB
- Hard Drive Bays:
- 2
- HDMI Outputs:
- 1
- Remote Users:
- 128
- Connection Type:
- Wired
- Wired Connection Type:
- IP
- U Size:
- 1U
- Weight:
- 5.952 lbs
