Allied 8-Channel 4K U-Series Hybrid DVR
$329.40
A true 4K hybrid DVR for eight BNC cameras and eight added IP channels, with 8MP recording, two drive bays, 32TB total capacity, and smart video investigation tools.
- Eight TVI Channels Plus Up to Eight IP Cameras
- 4K Recording Without Abandoning Existing Coax
- Two Drive Bays Support up to 32TB
- Search by Face, Behavior or Direction
- Room to Modernize at Your Own Pace
Connection & Power
Storage & Access
Resolution
Higher resolution records more pixels in each frame, which gives you more detail to work with when reviewing faces, vehicles, packages, and activity.
Resolution labels describe output dimensions. Aspect ratio, lens quality, sensor quality, lighting, compression, and recorder settings also affect usable image detail.
Frame Rate
Frame rate measures how many images a camera records each second. Higher FPS makes fast movement appear smoother and easier to follow.
The highlighted lane shows this product's maximum listed frame rate. Actual FPS can vary by resolution, recording mode, recorder, and system settings.
Description
The Allied 8-Channel 4K U-Series Hybrid DVR is for customers who want more detail than a Lite-resolution recorder while keeping existing BNC camera wiring. It records eight analog channels at up to 8MP 4K resolution and can add eight IP streams, or handle up to 16 IP cameras when the analog inputs are converted.
That flexibility works well for a higher-end home, storefront, or small commercial property where a few critical cameras need sharper evidence. Two internal bays support up to 16TB each, for 32TB total, and H.265 compression helps control the storage impact of 4K footage. Within Allied’s video security and surveillance systems, the U-Series provides a useful bridge between legacy cabling and modern high-resolution cameras.
UMD, smart intrusion prevention, face detection, and behavior search help turn a large recording timeline into a faster investigation. Choose this model when eight primary wired views need true 4K recording and generous IP expansion.
Key Features
- 8 BNC channels plus 8 additional IP channels
- Up to 16 total IP streams in all-IP mode
- True 8MP 4K recording
- 4K HDMI local display
- Two drive bays, up to 16TB each and 32TB total
- H.265 and H.264 compression
- UMD, smart intrusion, face, and behavior search
Full Specifications
- Megapixels:
- 8
- Resolution:
- 4K
- FPS:
- 30
- Smart Features:
- Advanced Motion Detection, Behavior Search, Directional Trip Wire, Face Search, Intelligent people flow counting, UMD (human,vehicle,pet) Detection
- Additional IP Channels:
- 8
- Built-in PoE Ports:
- 0
- Channels:
- 8
- Decoding Format:
- H.264, H.265
- DVR/NVR Storage Capacity:
- 32TB
- Hard Drive Bays:
- 2
- HDMI Outputs:
- 1
- Remote Users:
- 128
- Connection Type:
- Wired
- U Size:
- 1U
- Weight:
- 4.409 lbs
