Allied 4-Channel 5MP Hybrid DVR
$178.61
A compact four-channel hybrid DVR with 5MP and 8MP Lite recording, two additional IP camera channels, 4K HDMI output, and up to 16TB of storage.
- Sharper 5MP Recording for Four-Camera Systems
- Keep TVI Cameras and Add Up to Two IP Models
- Up to 16TB for Extended Video History
- Intelligent Search Makes Playback Less Tedious
- Compact Value for Homes and Small Businesses
Connection & Power
Storage & Access
Resolution
Higher resolution records more pixels in each frame, which gives you more detail to work with when reviewing faces, vehicles, packages, and activity.
Resolution labels describe output dimensions. Aspect ratio, lens quality, sensor quality, lighting, compression, and recorder settings also affect usable image detail.
Frame Rate
Frame rate measures how many images a camera records each second. Higher FPS makes fast movement appear smoother and easier to follow.
The highlighted lane shows this product's maximum listed frame rate. Actual FPS can vary by resolution, recording mode, recorder, and system settings.
Description
The Allied 4-Channel 5MP Hybrid DVR is a focused recorder for a home, office suite, or small storefront that needs dependable coverage without paying for unused channels. It accepts four BNC camera feeds and adds two IP camera channels, allowing up to six IP streams when the analog inputs are converted.
Current hardware supports 5MP and 8MP Lite recording with a 4K HDMI display, giving the installer room to preserve more detail than a basic 1080p recorder. H.265 compression makes better use of the single drive bay, which supports up to 16TB. For a property keeping existing coax while improving selected views, Allied’s security camera installation options can combine proven BNC wiring with new IP cameras where they add the most value.
Ultra Motion Detection, intrusion and cross-line rules, face search, and behavior search help narrow a review to meaningful activity. It is an efficient choice for four primary camera positions with a little expansion room built in.
Key Features
- 4 BNC camera channels plus 2 additional IP channels
- Up to 8MP Lite and 5MP Lite recording
- 4K HDMI local display output
- One hard-drive bay supporting up to 16TB
- H.265 and H.264 video compression
- UMD, smart intrusion, face, and behavior search tools
- Up to 128 remote users
Full Specifications
- FPS:
- 30
- Smart Features:
- Advanced Motion Detection, Behavior Search, Directional Trip Wire, Face Search, Intelligent people flow counting, UMD (human,vehicle,pet) Detection
- Additional IP Channels:
- 2
- Built-in PoE Ports:
- 0
- Channels:
- 4
- Decoding Format:
- H.264, H.265
- DVR/NVR Storage Capacity:
- 16TB
- Hard Drive Bays:
- 1
- HDMI Outputs:
- 1
- Remote Users:
- 128
- Connection Type:
- Wired
- U Size:
- 1U
- Weight:
- 2.425 lbs
