Alarm.com ADC-VDB775 Premium 4MP Video Doorbell, White
$220.05
Alarm.com compatible subscription required.
See more of the front step with 4MP HDR video and a 150-degree horizontal and vertical view. The white Alarm.com ADC-VDB775 adds intelligent people, package, animal and vehicle alerts, directional tripwires, two-way audio, proactive deterrence and continuous microSD recording to a clean, battery-free doorbell design.
- Clear 2K Detail from a Wide 150-Degree View
- Package Detection for Everyday Deliveries
- Answer the Door from Anywhere in the App
- Cloud Recording with Local SD Support
- Clean White Finish for Light Door Trim
Connection & Power
2.4 & 5 GHz Signal
AC/DC Powered
Storage & Access
Cloud Storage
Up to 1TB MicroSD
Deterrence Features
Audio Deterrence
Resolution
Higher resolution records more pixels in each frame, which gives you more detail to work with when reviewing faces, vehicles, packages, and activity.
Resolution labels describe output dimensions. Aspect ratio, lens quality, sensor quality, lighting, compression, and recorder settings also affect usable image detail.
Field of View
Doorbell coverage depends on both width and height. The overlays compare this product with a representative industry average and the widest doorbell in the Eco Smart catalog.
- This Product
- 150° H x 150° V
- Average
- 140° H x 115° V
- Max
- 165° H x 150° V
Coverage is a centered visual comparison, not a lens simulation. Placement and mounting angle also affect the final view.
Night Vision
Night-vision technologies solve different problems. Compare the same scene below; this product's supported modes are highlighted.
On this product
IR Night Vision
Black-and-white visibility without visible light, ideal for discreet overnight monitoring.
Dual Light
Uses IR normally, then activates a spotlight for full-color detail when it matters.
Color Night Vision
Retains useful color from ambient light without requiring a visible spotlight.
Ultra Color Night Vision
Advanced low-light processing preserves the clearest color and background detail in very dark scenes.
The examples explain relative viewing modes. Actual brightness, color, and range depend on the camera, placement, and available ambient light.
Night Viewing Range
Centered distance markers show how far this doorbell is rated to view from the porch.
"Up to" is the manufacturer-listed maximum viewing or illumination distance. Recognizable detail may be shorter and varies with lighting, night-vision mode, weather, placement, lens settings, and obstructions.
Description
The white Alarm.com ADC-VDB775 is designed for front entries where broad visibility and a clean appearance both matter. Its 2048 x 2048 4MP HDR image covers 150 degrees horizontally and vertically, helping you see a visitor from head to toe along with packages placed close to the door. Infrared illumination extends to approximately 15 feet for a usable view after dark.
Video Analytics distinguishes people, packages, animals and vehicles instead of treating every movement the same. Up to three simultaneous rules can be configured, and directional tripwires can distinguish someone approaching the entry from a person walking away. Package alerts, Perimeter Guard and manually triggered warning sounds give the doorbell practical ways to notify and respond before an event becomes a missed moment.
For live interaction, full-duplex two-way audio lets you speak with visitors through a compatible Alarm.com app or website. A compatible microSD card up to 1TB adds continuous onboard recording, while dual-band 2.4 and 5 GHz Wi-Fi with 2×2 MIMO supports a more resilient wireless connection. Video is compressed with H.264 to balance image quality and storage use.
The battery-free design connects to compatible 16-24 VAC or supported DC doorbell power and includes a mechanical chime dongle. Its white housing works naturally with light trim and modern entry hardware, while the IP65 enclosure and -58 to 122 degree Fahrenheit operating range prepare it for exposed Texas entryways.
Key Features
- 4MP HDR video with 2048 x 2048 maximum resolution
- 150-degree horizontal and 150-degree vertical field of view
- People, package, animal and vehicle detection
- Directional tripwires with support for up to three simultaneous Video Analytics rules
- Full-duplex two-way audio
- Perimeter Guard and manually triggered warning sounds
- Continuous onboard recording with compatible microSD cards up to 1TB
- Dual-band 2.4 and 5 GHz Wi-Fi with 2x2 MIMO
- Infrared night vision up to approximately 15 feet
- Battery-free wired design for compatible AC or DC doorbell power
- Mechanical chime dongle included
- IP65 weather-resistant enclosure
- Operating range from -58 to 122 degrees Fahrenheit
- Compact 1.81 x 5.26 x 1.34-inch body
Full Specifications
- Megapixels:
- 4
- Resolution:
- 2K
- Field of View:
- 150° H / 150° V
- HDR:
- Yes
- Sensor:
- 1/3.11"
- Lens Type:
- Fixed
- Night Vision:
- IR
- Night Viewing Range:
- 15ft
- Smart Features:
- Directional Trip Wire, Package Detection, Perimeter Guard, Smart Object Detection, Video Analytics
- Audio Features:
- 2-Way Audio
- Deterrence Features:
- Audio
- Video Encoding Format:
- H.264
- Max SD Storage:
- 1TB
- Connection Type:
- Wireless
- Wi-Fi Connection Type:
- 2.4 & 5 GHz
- Wireless Connection Type:
- Wi-Fi
- Powered by:
- AC/DC
- Placement:
- Outdoor
- Waterproof Rating:
- IP65
- Weight:
- 1 lbs
- Dimensions:
- 5.26 × 1.81 × 1.34 in
A compatible Alarm.com video service plan is required, and available analytics depend on the selected plan and location.
