Uniview IPC94144SFW-X25-F40C Dual 4MP MultiView 25x PTZ Camera
$1,010.19
Keep a fixed overview while a separate 25x PTZ channel inspects detail, with channel-specific warm-light and infrared illumination.
- Separate Overview and Detail Views
- 25x Optical Zoom on Detail Channel
- 100 m Detail-Channel IR
- Linked Target Tracking
Storage & Access
Up to 512GB MicroSD
Access Anywhere
ONVIF Compatible
Resolution
Higher resolution records more pixels in each frame, which gives you more detail to work with when reviewing faces, vehicles, packages, and activity.
Resolution labels describe output dimensions. Aspect ratio, lens quality, sensor quality, lighting, compression, and recorder settings also affect usable image detail.
Night Vision
Night-vision technologies solve different problems. Compare the same scene below; this product's supported modes are highlighted.
IR Night Vision
Black-and-white visibility without visible light, ideal for discreet overnight monitoring.
Dual Light
Uses IR normally, then activates a spotlight for full-color detail when it matters.
On this product
Color Night Vision
Retains useful color from ambient light without requiring a visible spotlight.
Ultra Color Night Vision
Advanced low-light processing preserves the clearest color and background detail in very dark scenes.
The examples explain relative viewing modes. Actual brightness, color, and range depend on the camera, placement, and available ambient light.
Night Viewing Range
A football field is 300 feet from goal line to goal line. The far end zone extends this comparison to 330 feet.
"Up to" is the manufacturer-listed maximum viewing or illumination distance. Recognizable detail may be shorter and varies with lighting, night-vision mode, weather, placement, lens settings, and obstructions.
Frame Rate
Frame rate measures how many images a camera records each second. Higher FPS makes fast movement appear smoother and easier to follow.
The highlighted lane shows this product's maximum listed frame rate. Actual FPS can vary by resolution, recording mode, recorder, and system settings.
Description
The IPC94144SFW-X25-F40C combines two independent 4MP views: a fixed 4 mm overview camera and a 4.8-120 mm PTZ detail camera with 25x optical zoom. Each channel reaches 2688 x 1520 at 30 fps. The fixed view can trigger the detail camera to track activity through the linkage function.
Night coverage is deliberately different on the two channels: 30 m warm light for the overview and 100 m infrared for detail. The PTZ channel provides 360-degree pan and -15 to 90-degree tilt. A built-in speaker, external audio input, 512 GB microSD support and IP66 protection support monitoring and response from one installation.
Key Features
- Two independent 4MP channels, each up to 2688 x 1520 at 30 fps; not a single 8MP/4K stream
- Overview: 1/1.8-inch CMOS, 4 mm F1.0 fixed lens, horizontal FOV 94.9 degrees
- Detail: 1/2.7-inch CMOS, 4.8-120 mm lens, 25x optical zoom, horizontal FOV 55.46 to 3.09 degrees
- Overview illumination: warm light up to 30 m; no overview IR specified
- Detail illumination: IR up to 100 m; no detail warm light specified
- Detail PTZ: 360-degree pan; tilt -15 to 90 degrees
- Fixed-camera intrusion detection can trigger PTZ target tracking
- 120 dB WDR; built-in speaker; no built-in microphone
- MicroSD up to 512 GB; ANR network storage recovery
- 12 V DC or IEEE 802.3at PoE+; maximum 24 W; IP66
Full Specifications
- Megapixels:
- 4
- Resolution:
- 2688 x 1520 (Per Channel)
- Field of View:
- 55.46° – 3.09° (Detail, H), 94.9° (Overview, H)
- FPS:
- 30
- WDR:
- 120 dB
- Sensor:
- 1/1.8" (Overview), 1/2.7" (Detail)
- Lens Type:
- Fixed (Overview), Motorized (Detail)
- Optical Zoom:
- 25X (Detail)
- PTZ Pan Range:
- 360° (Detail)
- PTZ Tilt Range:
- -15° to 90° (Detail)
- Night Vision:
- Color Night Vision (Overview); IR (Detail)
- Night Viewing Range:
- 98ft (Overview, Warm Light); 328ft (Detail, IR)
- Smart Features:
- Human Body Detection, Intrusion Detection, Line Crossing Detection, Linked Target Tracking, Vehicle Detection
- Audio Features:
- 2-Way Audio (External Microphone Required), Built-in Speaker
- Video Encoding Format:
- Ultra 265, H.265, H.264, MJPEG
- Max SD Storage:
- 512GB
- Storage Type:
- SD Card
- Connection Type:
- Wired
- ONVIF Compatible:
- Yes
- Wired Connection Type:
- IP
- Waterproof Rating:
- IP66
- Weight:
- 5.004 lbs
- Dimensions:
- 11.97 × 7.68 × 6.42 in
Two-way communication may require external audio equipment; see the audio specifications for this model.
