Uniview PKC2640@Z80-IR-P 4MP ANPR IR Bullet Camera, 8-32 mm
$1,221.59
Capture license plates on access roads with a dedicated 4MP ANPR camera, an 8-32 mm lens and configurable vehicle allowlists.
- Dedicated License-Plate Recognition
- 8-32 mm Lane Framing
- 50 m Infrared Illumination
- 20,000-Entry Access Lists
Storage & Access
Up to 256GB MicroSD
Access Anywhere
ONVIF Compatible
Resolution
Higher resolution records more pixels in each frame, which gives you more detail to work with when reviewing faces, vehicles, packages, and activity.
Resolution labels describe output dimensions. Aspect ratio, lens quality, sensor quality, lighting, compression, and recorder settings also affect usable image detail.
Field of View
The centered overlays compare this product's horizontal coverage with a representative industry average and the widest security camera in the Eco Smart catalog.
- This Product
- 42.4° horizontal
- Average
- 105° horizontal
- Max
- 180° horizontal*
*180° horizontal coverage generally requires a dual-lens panoramic camera.
Coverage is a centered visual comparison, not a lens simulation. Placement and mounting angle also affect the final view.
Night Vision
Night-vision technologies solve different problems. Compare the same scene below; this product's supported modes are highlighted.
On this product
IR Night Vision
Black-and-white visibility without visible light, ideal for discreet overnight monitoring.
Dual Light
Uses IR normally, then activates a spotlight for full-color detail when it matters.
Color Night Vision
Retains useful color from ambient light without requiring a visible spotlight.
Ultra Color Night Vision
Advanced low-light processing preserves the clearest color and background detail in very dark scenes.
The examples explain relative viewing modes. Actual brightness, color, and range depend on the camera, placement, and available ambient light.
Night Viewing Range
A football field is 300 feet from goal line to goal line. The far end zone extends this comparison to 330 feet.
"Up to" is the manufacturer-listed maximum viewing or illumination distance. Recognizable detail may be shorter and varies with lighting, night-vision mode, weather, placement, lens settings, and obstructions.
Frame Rate
Frame rate measures how many images a camera records each second. Higher FPS makes fast movement appear smoother and easier to follow.
The highlighted lane shows this product's maximum listed frame rate. Actual FPS can vary by resolution, recording mode, recorder, and system settings.
Description
The PKC2640@Z80-IR-P combines license-plate recognition and vehicle access control in a weather-resistant bullet camera. Its 8-32 mm lens lets installers frame a traffic lane, and the manufacturer specifies road applications at speeds up to 80 km/h. Main-stream capture reaches 2688 x 1520 at 30 fps.
This is the infrared version, with four IR LEDs and illumination rated up to 50 m. Allowlist and blocklist capacity is 20,000 entries each, and relay output supports configurable barrier-opening policies. A built-in junction box stores the tail cable; power comes from 12 V DC or 802.3at PoE.
Key Features
- 4MP, 1/1.8-inch CMOS; 2688 x 1520 at up to 30 fps
- 8-32 mm lens; horizontal FOV 42.4 to 15.9 degrees
- IR-P variant: four infrared LEDs, illumination up to 50 m; not the warm-light P variant
- Road applications up to 80 km/h; plate capture still depends on installation geometry and regional plate support
- Allowlist and blocklist: 20,000 entries each
- One barrier-control relay output; two Boolean inputs; RS485
- MicroSD up to 256 GB with ANR
- 120 dB WDR; H.264 and H.265 compression
- IP67 and IK10; built-in junction box
- 12 V DC or IEEE 802.3at Class 4 PoE; maximum 20 W
Full Specifications
- Megapixels:
- 4
- Resolution:
- 2688 x 1520
- Field of View:
- 42.4° – 15.9°
- FPS:
- 30
- WDR:
- 120 dB
- Sensor:
- 1/1.8"
- Lens Type:
- Varifocal
- Night Vision:
- IR
- Night Viewing Range:
- 164ft
- Smart Features:
- License Plate Reader
- Audio Features:
- Audio Input, Audio Output
- Video Encoding Format:
- H.265, H.264
- Max SD Storage:
- 256GB
- Storage Type:
- SD Card
- Connection Type:
- Wired
- ONVIF Compatible:
- Yes
- Wired Connection Type:
- IP
- Waterproof Rating:
- IP67
- Weight:
- 4.630 lbs
- Dimensions:
- 15.98 × 4.96 × 5.12 in
