Uniview IPC3634SR4-ADZK-H 4MP 2.8-12mm Motorized IR Turret Network Camera
$360.89
Adjust framing with a 2.8-12mm motorized lens and monitor at 4MP resolution up to 25 fps. Infrared illumination reaches 40 m, with a built-in microphone for audio capture.
- 2.8-12mm Motorized Lens
- 4MP Video at 25 fps
- 40 m Infrared Illumination
- Human-Based Perimeter Detection
Storage & Access
Up to MicroSD Compatible MicroSD
Access Anywhere
ONVIF Compatible
Resolution
Higher resolution records more pixels in each frame, which gives you more detail to work with when reviewing faces, vehicles, packages, and activity.
Resolution labels describe output dimensions. Aspect ratio, lens quality, sensor quality, lighting, compression, and recorder settings also affect usable image detail.
Field of View
The centered overlays compare this product's horizontal coverage with a representative industry average and the widest security camera in the Eco Smart catalog.
- This Product
- 86.3° horizontal
- Average
- 105° horizontal
- Max
- 180° horizontal*
*180° horizontal coverage generally requires a dual-lens panoramic camera.
Coverage is a centered visual comparison, not a lens simulation. Placement and mounting angle also affect the final view.
Night Vision
Night-vision technologies solve different problems. Compare the same scene below; this product's supported modes are highlighted.
On this product
IR Night Vision
Black-and-white visibility without visible light, ideal for discreet overnight monitoring.
Dual Light
Uses IR normally, then activates a spotlight for full-color detail when it matters.
Color Night Vision
Retains useful color from ambient light without requiring a visible spotlight.
Ultra Color Night Vision
Advanced low-light processing preserves the clearest color and background detail in very dark scenes.
The examples explain relative viewing modes. Actual brightness, color, and range depend on the camera, placement, and available ambient light.
Night Viewing Range
The bird's-eye property guide shows how the camera's listed nighttime range extends outward from its mounting point.
"Up to" is the manufacturer-listed maximum viewing or illumination distance. Recognizable detail may be shorter and varies with lighting, night-vision mode, weather, placement, lens settings, and obstructions.
Frame Rate
Frame rate measures how many images a camera records each second. Higher FPS makes fast movement appear smoother and easier to follow.
The highlighted lane shows this product's maximum listed frame rate. Actual FPS can vary by resolution, recording mode, recorder, and system settings.
Description
The IPC3634SR4-ADZK-H offers adjustable coverage through its 2.8-12mm motorized lens. The horizontal field of view ranges from 86.3 to 35.2 degrees, allowing a wider overview or a tighter view of a selected area. Its 4MP stream reaches 25 fps, with 120 dB WDR and up to 40 m of IR illumination.
Human-based crossing and intrusion detection support perimeter alerts without requiring a PTZ camera. A built-in microphone captures audio, and a microSD slot supports local recording. The IP67 metal body supports outdoor mounting and either PoE or 12V DC power.
Key Features
- 4MP video: 2688 x 1520 at up to 25 fps
- 2.8 to 12 mm motorized varifocal lens; F1.6
- Horizontal field of view: 86.3 degrees to 35.2 degrees
- Sensor: 1/3.0 inch CMOS
- Wide dynamic range: 120 dB
- Infrared illumination up to 40 m
- MicroSD recording supported; maximum card capacity requires manufacturer confirmation
- Video encoding: Ultra 265, H.265, H.264, MJPEG
- Power: IEEE 802.3af PoE or 12V DC
- Network: RJ45 10/100 Mbps Ethernet
- ONVIF (Profile S, Profile G, Profile T)
- Integrated microphone
- Human-based line-crossing and intrusion events
- Environmental protection: IP67
Full Specifications
- Megapixels:
- 4
- Resolution:
- 2688 x 1520
- Field of View:
- 86.3° – 35.2°
- FPS:
- 25
- WDR:
- 120 dB
- Sensor:
- 1/3"
- Lens Type:
- Motorized
- Night Vision:
- IR
- Night Viewing Range:
- 131ft
- Smart Features:
- Human Body Detection, Intrusion Detection, Line Crossing Detection, Motion Detection
- Audio Features:
- Audio Capture
- Video Encoding Format:
- Ultra 265, H.265, H.264, MJPEG
- Storage Type:
- SD Card
- Connection Type:
- Wired
- ONVIF Compatible:
- Yes
- Wired Connection Type:
- IP
- Waterproof Rating:
- IP67
- Weight:
- 1.455 lbs
- Dimensions:
- 5.08 × 5.08 × 4.33 in
