Yale Assure Lever YRL226 Z-Wave Lock – Satin Nickel
$336.15
Secure a compatible single-bore lever door with a touchscreen, Z-Wave Plus control, auto-lock, and keyed backup in Satin Nickel.
- Touchscreen Smart Lock for Lever-Style Doors
- Control Access Through a Connected Z-Wave System
- Emergency 9V Power Helps Avoid Lockouts
- Lock with One Touch and Let Auto-Lock Follow
- Satin Nickel for a Clean Contemporary Look
Description
The Yale Assure Lever YRL226 presents a smooth touchscreen on a Grade 2 lever lock for compatible single-bore openings. Automatic relocking and Z-Wave Plus control support managed access, while keyed backup remains available when needed.
Satin Nickel gives the touchscreen Assure Lever a clean, adaptable appearance for offices, interior suites, and residential side doors. The flat keypad stays dark when idle, keeping the hardware visually restrained.
The reversible lever fits common 1-3/8 to 1-3/4 inch doors with 2-3/8 or 2-3/4 inch backsets.
Key Features
- Touchscreen keyless entry
- Z-Wave Plus connectivity
- Automatic relocking option
- Physical key backup
- Exterior 9V emergency-power contacts
- Reversible lever for left- or right-handed doors
- Designed for single-bore doors without a deadbolt
- Fits 1-3/8 to 1-3/4 inch door thickness
- Four AA alkaline batteries
- ANSI/BHMA Grade 2 security
Full Specifications
- Connection Type:
- Wireless
- Smart Home Protocol:
- Z-Wave Plus
- Wireless Connection Type:
- Z-Wave
- Wireless Frequency:
- 908.42 MHz
- Z-Wave Security:
- 128-Bit AES
- Keypad Type:
- Touchscreen
- Door Compatibility:
- 1-3/8 to 1-3/4 in Door Thickness, 2-3/8 or 2-3/4 in Backset, Left- or Right-Handed Door, Single-Bore Door
- Lock Features:
- 9V Emergency Power, Auto-Lock, One-Touch Locking, Physical Key Backup
- Lock Function:
- Lever Lock
- Battery Type:
- 4 x AA Alkaline
- Powered by:
- Battery
- Compliance & Certifications:
- ANSI/BHMA Grade 2, FCC
- Mounting Type:
- Door Mount
- Operating Temperature Range:
- -22 to 140 F
- Recommended Application:
- Light Commercial, Residential
- Device Type:
- Smart Lock
- Lifecycle Status:
- Active
- Product Color:
- Satin Nickel
- System Type:
- Smart Lever Lock
- Weight:
- 4.74 lbs
- Dimensions:
- 9 × 6.5 × 6.5 in
A physical key and exterior 9V emergency-power contacts provide two practical fallback paths; remote features still depend on a compatible Z-Wave controller and its service configuration.
