DSC HS2LCDRF9 Keypad with Built-In PowerG Transceiver
$198.45
Compatible with PowerSeries Neo HS2016, PowerSeries Neo HS2032, PowerSeries Neo HS2064, PowerSeries Neo HS2128 Control Panels
Combine full-message Neo control and wireless expansion in one device with a 2 x 16 LCD keypad and built-in 915 MHz PowerG transceiver for up to 128 wireless zones.
- Full-Message Keypad and PowerG Receiver in One
- Add Up to 128 Wireless Zones
- Custom Zone Labels Make Alerts Easy to Identify
- Built-In Receiver Saves Wall Space and Hardware
- Professional Control for Any Neo Panel
Description
The DSC HS2LCDRF9 does two jobs from one wall location: it provides the full-message keypad used to program and operate PowerSeries Neo, and it gives the panel a 915 MHz PowerG transceiver for compatible wireless sensors, life-safety devices, sirens, and key fobs.
That consolidation can simplify an existing system upgrade because the receiver is built into a device the installation already needs. The blue LCD supports 32-character labels, global partition status, menu programming, and outdoor temperature information, while five programmable keys accelerate frequent commands.
This RF model does not include a proximity reader. Choose it when codes are the preferred user credential and the panel needs PowerG reception. The supported wireless-device count follows the connected Neo panel, up to 128 zones.
Key Features
- Built-in 915 MHz PowerG transceiver
- Supports the connected panel's PowerG capacity up to 128 zones
- 2 x 16 full-message blue LCD
- 32-character programmable labels
- Global partition status
- Five programmable function keys
- Configurable zone-input or PGM-output terminal
- Emergency keys and adjustable keypad buzzer
- Dual tamper protection
- Four-wire Corbus panel connection
Full Specifications
- Compatible Panels:
- PowerSeries Neo HS2016, PowerSeries Neo HS2032, PowerSeries Neo HS2064, PowerSeries Neo HS2128
- Wired Connection Type:
- Corbus
- Wireless Connection Type:
- PowerG
- Wireless Frequency:
- 915 MHz
- Integrated Wireless Receiver Capacity:
- 128 Zones
- Maximum Compatible Keypads:
- 16
- Maximum Total Zones:
- 128
- Display Characters:
- 32 Character
- Display Language:
- English, Multilingual
- Display Type:
- Full-Message LCD
- Keypad Features:
- Arm/Disarm Controls, Audible Chimes and Alerts, Built-in PowerG Transceiver, Custom Zone Labels, Emergency Keys, Global Partition Status, Input/Output Terminal, Low-Temperature Sensor, Menu Programming, Outdoor Temperature Display, Programmable Function Keys, Status LEDs, Tamper Protection
- Keypad Interface:
- Physical Buttons
- Keypad Orientation:
- Landscape
- Power Input:
- 12V DC
- Powered by:
- DC
- Mounting Type:
- Wall Mount
- Recommended Application:
- Commercial, Light Commercial, Residential
- Product Color:
- White
- Weight:
- 0.57 lbs
- Dimensions:
- 6.61 × 4.80 × 0.79 in
