DSC HS2LCD PowerSeries Neo Full-Message Keypad
$152.55
Compatible with PowerSeries Neo HS2016, PowerSeries Neo HS2032, PowerSeries Neo HS2064, PowerSeries Neo HS2128 Control Panels
Program and operate PowerSeries Neo from a hardwired 2 x 16 full-message LCD keypad with 32-character labels, five function keys, and a configurable I/O terminal.
- Plain-Text Status Is Easier to Understand
- See Which Door or Sensor Opened by Name
- Built for Neo Panels with as Many as 128 Zones
- Programmable Shortcuts Speed Up Daily Use
- See Outdoor Temperature at the Keypad
Description
The DSC HS2LCD is the text-driven keypad for PowerSeries Neo installations that need clear zone names and guided menu programming. Its blue 2 x 16 display supports 32-character labels, global partition status, multiple languages, and outdoor-temperature information, reducing the guesswork that comes with icon-only keypads.
A hardwired four-wire Corbus connection supplies dependable power and panel communication. Five programmable keys speed up frequent commands, while the I/O terminal can serve as a zone input or PGM output. In a tailored home security system, Allied can place it at the entry used most often and program labels around the property’s actual rooms and doors.
It is the right choice when the panel already has the wireless hardware it needs and the priority is a clear, full-message programming interface.
Key Features
- 2 x 16 full-message blue LCD
- Full 32-character programmable labels
- Global partition status
- Multi-language menu programming
- Five programmable function keys
- Configurable zone-input or PGM-output terminal
- Fire, medical, and panic controls
- Adjustable backlight and keypad buzzer
- Front-cover and wall-mount tamper protection
- Compatible with PowerSeries Neo panels
Full Specifications
- Compatible Panels:
- PowerSeries Neo HS2016, PowerSeries Neo HS2032, PowerSeries Neo HS2064, PowerSeries Neo HS2128
- Connection Type:
- Wired
- Wired Connection Type:
- Corbus
- Maximum Compatible Keypads:
- 16
- Maximum Total Zones:
- 128
- Display Characters:
- 32 Character
- Display Language:
- English, Multilingual
- Display Type:
- Full-Message LCD
- Keypad Features:
- Arm/Disarm Controls, Audible Chimes and Alerts, Custom Zone Labels, Emergency Keys, Global Partition Status, Input/Output Terminal, Low-Temperature Sensor, Menu Programming, Outdoor Temperature Display, Programmable Function Keys, Status LEDs, Tamper Protection
- Keypad Interface:
- Physical Buttons
- Keypad Orientation:
- Landscape
- Power Input:
- 12V DC
- Powered by:
- DC
- Mounting Type:
- Wall Mount
- Recommended Application:
- Commercial, Light Commercial, Residential
- Product Color:
- White
- Weight:
- 0.57 lbs
- Dimensions:
- 6.61 × 4.80 × 0.79 in
This base HS2LCD model does not include proximity-tag support or a PowerG transceiver.
