DSC PG9WLSHW8 PowerG 8-Zone Wired-to-Wireless Converter
$167.40
Compatible with IQ Panel 2+, IQ Panel 4, Qolsys PowerG Panels Control Panels
Move existing hardwired protection onto a compatible Qolsys IQ system with 8 onboard zones, expansion to 24 zones, 4 PGM outputs, and wired smoke support.
Description
The DSC PG9WLSHW8 lets a compatible Qolsys IQ panel use existing hardwired detectors without replacing every door contact, motion sensor, smoke loop, and cable run. Eight onboard zones connect inside the cabinet, and two HSM2108 expansion slots can increase the hardwired total to 24 zones when the property needs more capacity.
The converter also provides four programmable outputs and support for up to eighteen compatible two-wire smoke detectors, plus four-wire smoke and carbon-monoxide devices. An 18V DC adapter powers the module, while an optional 12V 7Ah battery can provide backup operation. PowerG carries the converted zone events wirelessly to the control panel.
That makes the PG9WLSHW8 especially useful for an existing security system takeover where the field wiring remains valuable. Allied can map every circuit, identify resistor and detector requirements, test standby power and siren loading, then migrate the zones in a controlled sequence instead of treating the cabinet as a simple plug-in accessory.
Key Features
- 8 onboard hardwired zones
- Two HSM2108 expansion slots
- Up to 24 total hardwired zones
- Four onboard programmable outputs
- Support for up to 18 compatible two-wire smoke detectors
- Four-wire smoke and carbon-monoxide device support
- 18V DC power adapter input
- Optional 12V 7Ah backup battery
- PowerG communication to supported Qolsys IQ panels
- UL and ULC listed family
Full Specifications
- Sensor Type:
- Hardwire Takeover Module
- Expansion Slots:
- 2
- Compatible Panels:
- IQ Panel 2+, IQ Panel 4, Qolsys PowerG Panels
- Wired Connection Type:
- Corbus
- Wireless Connection Type:
- PowerG
- Wireless Frequency:
- 915 MHz
- Hardwired Zones:
- 8
- Maximum Hardwired Expansion Zones:
- 24
- Maximum Two-Wire Smoke Detectors:
- 18
- Onboard PGM Outputs:
- 4
- Backup Battery:
- Up to 12V 7Ah, Up to 24 hours
- Power Input:
- 18V DC
- Powered by:
- AC/DC
- Mounting Type:
- Surface Mount, Wall Mount
- Operating Temperature Range:
- 14 to 131 F
- Placement:
- Indoor
- Recommended Application:
- Commercial, Light Commercial, Residential
- Product Color:
- White
- System Type:
- Hardwire Takeover Module
- Weight:
- 6.28 lbs
- Dimensions:
- 9.8 × 8.9 × 3.1 in
